Ideally suited for smoothie and ice-cream shops, small spaces, counter-top bars, mobile carts, food courts, lounges, boats, caterers, dental offices, day-care operators, guest hoses, room service, espresso bars, kiosks, laboratories, and much more!
Performance Features
- Completely automatic wash and rinse cycles including one wash program at 150°F (65°C) and one rinse program at 185°F (85°C).
- Hourly Production: 20 racks of various items or depending on rack insert used, the following quantities can be washed and rinsed:
- 4-Place insert for Blender Containers - 80 / hr.
- 9-Place insert for Glassware - 180 / hr.
- 16-Place insert for Glassware - 320 / hr.
- 6-Place insert for Dishes - 120 / hr.
- Built-in automatic detergent pump for consistent results each time.
- Built-in automatic rinse-additive pump for sparkling final results.
Construction Features
- Body, external housing, wash tank, and all chassis components in brushed stainless steel 304 18/10.
- Constructed of insulated double-walled panels for low heat and noise emissions.
- Unique and compact size for easy placement on a counter top, stand, or mobile cart.
- Door opening is designed to accept items up to a maximum height of 11".
- Integrated stainless steel booster with insulated lining.
- Full width interior scrap screens of durable stainless steel.
- Internal screen for protection of motor-pump.
- Safety micro-switch on the door to interrupt wash pump action.
- Lower revolving wash and rinse arm with lateral upper fixed rinse arms built of fiberglass designed for maximum results and easy of maintenance.
- Independently-operated heating elements alternating between the booster and wash tank.
- Both alternating heating elements serve to reduce overall energy costs by lowering amperage consumption.
- Thermostatic regulated control of both wash and rinse water.
- Automatic fill and water level regulation of the wash tank.
- Individual thermometer gauges for both washing and rinse temperatures.
- Vertical integrated control panel for simple access and technical maintenance.
Accessories
- Includes:
- (1) open rack - 13.75" x 13.75"
- (1) 4-place insert for blender containers
- (1) 9-place insert for glassware
- (1) 6-place insert for plates up to 10.5"
- (1) 15-place insert for saucers and or small plates
- Optional:
- 16-place insert for glassware
Technical Features
- Rack capacity: 13.75" x 13.75"
- Complete operating cycle: 165 seconds wash and 15 seconds rinse.
- Wash tank capacity: 2.1 gal
- Wash tank element: 1400 Watts
- Wash temperature: 150°F (65°C)
- Booster capacity: .65 gal
- Booster element: 1400 Watts
- Rinse (water) temperature: 185°F (85°C)
- Maximum power absorption: 1500 Watts
- Wash motor-pump: 100 Watts
- Power supply: 110 Volt / 60 Hz
- Optional: 220 Volt / 50 Hz
- Amperage: Single phase - 13.5A
- Water consumption: .5 gal per cycle
- Recommended pressure: 25 psi
- Water inlet connection: 3/4" male garden hose fitting (hose included)
- Drain connection: 1" ID hose connection (hose included)
- Shipping Weight: 72 lbs
Features
Door Design
Door Opening
Racks Per Hour
Electrical
Amperage
Frequency
Voltage
Warranties
Warranty
Weight
72 lb
