Complete stainless steel construction designed to withstand heavy-duty applications.
Easily removable lid, cylinder, and piston for thorough cleaning and sanitation, ensuring the highest levels of hygiene and safety.
Equipped with IP 67 waterproof and dustproof protection switch and flow dial regulator.
Side-mounted foot switch for convenient operation.
Automatic piston decompression and shut-off.
Includes a four (4) stainless steel funnel set: 1/2”, 5/8”, 7/8”, and 1 3/8”.
Features a dial adjustment and hydraulic oil AW 46 tank with level gauge.
Features
Technical:
The machine is completely made of stainless steel for durability and long life.
Silicone gaskets inside the cylinder provide a better seal and extended gasket life.
Side-mounted foot switch enhances operator comfort.
Includes a stainless steel 4-funnel set (1/2”, 5/8”, 7/8”, 1 3/8”).
Safety:
Equipped with overload and no-voltage release protection.
Sanitary:
The machine can be completely disassembled for easy and accurate sanitation.
Specifications
- Motor: 0.75 Hp (520 W), fan-cooled.
- Electrical: 230V AC, 60Hz, Single Phase, 4.2 Amps (+/- 10%).
- Plug & Cord: Attached, flexible, 3-wire SJT 14 AWG, 6'4" long cord, NEMA 6-15 P plug.
- Controls: ON/OFF stainless steel keypad with IP 67 waterproof protection, no-voltage release. Recommended 10 min ON / 15 min OFF cycle.
Package Quantity
1
